Cane Creek
ASSEMBLED BY HAND IN ASHEVILLE, NC
Cane Creek is deeply rooted in cycling. Our innovative heritage is as rich as the Blue Ridge Mountains that surround our company in North Carolina. Ideas that emerged within our walls were the introduction of helical control sets, winning AngleSet solutions, Double Barrel suspension platforms, and superior Climb Switch technology. All these innovations have proved to be a breakthrough for future bike development and performance. The approach to our product development illustrates our commitment to technology and craftsmanship. This often leads us to leave the conventional route, but we remain committed to driving innovation to offer the driver more and nothing less.
Highlights
DB Tigon coilshock
Details
Next Gen spring damper with air/spring hybrid synergy for Trail and Enduro
Twin Tube technology (oil circulation through 2 high-speed and 2 low-speed valves)
Ramp Tube technology (secondary air spring to adjust the progression of the shock)
Up to 35% more progression compared to conventional spring dampers
Independent high & low-speed compression, low-speed rebound with 2-position climb switch
Tool-free adjustment of the high-speed compression
Low speed settings with indexed positions (low speed compression 11 clicks / low speed rebound 13 clicks)
Climb switch mode: 2-way adjustable low-speed compression stage to optimize pedalling efficiency with simultaneous bob suppression
Shaft diameter: 12.7mm for higher lateral stiffness
Integrated hexagon for mobile adjustment
Handmade in Fletcher/USA
Weight: 438g (210mm without spring)
MSRP: 899,99€
Invert Gravel fork
Details
Lightweight, aesthetic high-end air suspension fork for gravel
Available as an extra-light SL version or as a CS version with Climb Switch mode
Wheel size: 700C
Suspension travel: 30mm (SL), 40mm (CS)
Fork bridge head tube unit made of carbon with laminated aluminum dip tubes
One-piece forged and milled stanchions with discreetly integrated disc brake mount and thru axle
Brake disc: 160mm flatmount (incl. bolts), 180mm possible with 20mm flatmount rear wheel adapter
Tire clearance up to max. 50mm
stanchions: 30mm butted aluminum
Steerer tube: 1.5>1 1/8" tapered carbon
Installation height: 425mm (SL), 435mm (CS)
Offset: 45mm
12x100mm thru axle (incl.)
Suspension: undamped air suspension, Invert CS model additionally with Climb Switch mode
Weight: 990g (SL), 1,113g (CS)
Also included in the scope of delivery:
BAK0010 Cane Creek ANCORA Premium Expander
BAA1132 Cane Creek spare bearing ZN40, zinc plated, 52mm, 36x45°
MSRP: From 1299€ (Invert SL)
Hellbender 70 Headset (Chroma Studio)
Details
Reliable, durable headset with anodized surface
Now available in different anodized colors
Material: 6061 T-6 aluminum
Low-friction upper bearing seal and a double lower bearing seal for complete protection against dust, mud or other contaminants
Hard-wearing Hellbender stainless steel ball bearings for extreme conditions
MSRP: From 139,99€
