Surly
BIKES. PARTS. CHAOS.
Many have tried — and failed — to define Surly. Contrary to popular belief, we’re not a bunch of deranged, clown-obsessed, serial killer wannabes — well, not all of us. We’re not drunk 24/7 and we don’t live in the woods behind our office anymore. What we are is an assortment of personalities and humanoids all brought together by one common interest: bike nerdom. We make serious steel bikes for people who don’t take themselves too seriously.
We don’t like to talk down to other frame materials. Instead, we’re adamant that steel is the best material for the kinds of bikes we design and ride. Our ‘Natch!’ tubesets are designed by our engineers to match the intended use and loading characteristics of each individual model. Size-specific tubesets, Custom butting profiles, proprietary forks, design details out the wazoo... all these features create the “Surly Ride” – comfort and compliance – that is consistent across all Surly bikes.
Surly riders span the range of sizes and shapes while giving the finger to the principles of pinpoint marketing demographics. This isn’t some exclusive club. You’re welcome to join as long as you’re comfortable in your own skin. One thing Surly riders have in common is a penchant for cutting through bullshit. You don’t need to wear a uniform or kit to ride a Surly. Just throw your leg over and go.
Highlights
Krampus
Details
650B/700C Road Plus bike with generous tire clearance and mounting points for bikepacking and long-distance touring
Frame: 100% Surly 4130 CroMoly steel, double-butted main frame triangle, TIG-welded, electrocoated for corrosion protection
Fork: 1 1/8” Surly Midnight Special Disc fork, 100 x 12 mm installation width, flat-mount disc brake mount, mounting eyelets for mudguards and pannier rack
Headset: 44 mm head tube, compatible with ZS44/28.6 | ZS44/30.0 headsets
Brakes: Flat-mount disc brake mount, compatible with 140-160 mm brake rotors
Seatpost: 27.2 mm diameter, including Surly stainless steel seat clamp (30.0 mm)
Bottom bracket: 68 mm BSA thread
Tire clearance: 650B x 60 mm or 700C x 42 mm (without mudguards)
Wheel compatibility: 650B or 700C
Axles: 12 x 100 mm thru axle at the front, 12 x 142 mm thru axle at the rear
Color: Fool's Gold
Sizes: 40 cm, 46 cm, 50 cm, 54 cm, 56 cm, 58 cm, 60 cm
Special features: Mounts for pannier rack, mudguards and three bottle cages; optional down tube shifter mounting possible
MSRP: 799 €
Ogre
Details
Versatile 29-inch touring and bikepacking bike made of durable chromoly steel
Frame: 100% Surly chromoly steel, Natch tube set, double-butted main triangle, TIG-welded, ED-coated
Fork: 100% Surly chromoly steel, Natch tube set, double-butted, tapered fork blades, TIG-welded, ED-coated
Seatpost Clamp: Surly stainless steel 30.0 mm
Headset: Cane Creek
Brakes: Avid BB5 mechanical disc brakes
Brake Levers: Tektro FR5
Brake Rotors: 160 mm front / 160 mm rear
Shifters: Microshift SL-M9605 Trail Pro
Stem: Kalloy 31.8 mm
Handlebar: Salsa Bend
Grips: Velo Black
Saddle: WTB Volt
Seatpost: Promax 27.2 x 300 mm
Crankset: SRAM NX 32T
Bottom Bracket: SRAM Powerspline
Rear Derailleur: Microshift RD-M6205 with clutch
Cassette: 10-speed, 11-48T
Chain: KMC 10-speed
Wheelset: WTB i29 rims, tubeless-ready
Front Hub: Novatec 9 x 100 mm quick release, 6-bolt disc mount
Rear Hub: Novatec 12 x 142 mm quick release, 6-bolt disc mount
Tires: Surly ExtraTerrestrial 29 x 2.5", 60 TPI, tubeless-ready
Color: Fermented Plum
Sizes: S, M, L, XL
MSRP: 1,899.00 €
Bridge Club
Details
27.5" Touring wheel from 4130 CroMoly.
Frame: Bridge Club
Fork: Bridge Club
color: black
Rear derailleur: Shimano Deore M5100 SGS Shadow Plus
Cassette: Shimano Deore 11-speed, 11-51 T.I75
Chain: KMC X11
Crank: Shimano Deore FC-M100, 32 T.
Shift lever: Shimano Deore 11-speed, SL-M5100-R
Brakes and discs: Tektro HD-M275/276, 160mm discs.
Headset: Cane Creek
Stem: Promax, 31.8mm
Handlebar: Salsa Bend
Grips: Velo Black
Seatpost: Promax 27.2 x 350, 12mm offset
Saddle: WTB Volt
Front wheel: WTB ST i29 TCS 2.0 27.5" 32 hole, Tubeless ready, Novatec 9x100mm, 6-hole disc
Rear wheel: WTB ST i29 TCS 2.0 27.5" 32 hole, Tubeless ready, Novatec 9x141mm, 6-hole disc, 11-speed
Tires: WTB Trail Boss 27.5 x 2.4", 27 tpi
Frame details:
Fork height: 420mm rigid
Front brake (disc size): 51mm I.S. (203mm max rotor).
Rear brake (disc size): 51mm I.S. (180mm max rotor)
Fork installation width: 10x100mm
Rear wheel width: 10 x 135mm or 10 x 141mm
Headset size: EC34/28.6 (Upper) | EC34/30 (Lower)
bottom bracket: 73mm with thread
MSRP: 1499 EUR
